Nominal Input Level

-20 dBu

Input Impedance

1 M ohms

Nominal Output Level

-20 dBu

Output Impedance

1 k ohms

Recommended Load Impedance

10 k ohms or greater

Controls

Pedal Switch, MODE Switch, BODY Knob, TOP Knob, LEVEL Knob, REVERB Knob

Indicator

CHECK Indicator (Serves also as battery check indicator)

Connectors

INPUT Jack, G.OUT Jack, LINE OUT Jack, AC Adaptor Jack (DC 9 V)

Power Supply

DC 9 V: Dry Battery (6F22/ 9 V), AC Adaptor (PSA Series: Optional)

Current Draw

39 mA (DC 9 V)

Accessories

Owner's Manual, Dry Battery; 6F22/ 9 V (Carbon), Leaflet (“USING THE UNIT
SAFELY,” “IMPORTANT NOTES,” and “Information”)

Options

AC Adaptor PSA-Series

Size and Weight

Width

70 mm
2-13/16 inches

Depth

125 mm
4-15/16 inches

Height

55 mm
2-3/16 inches

Weight

440 g
1 lbs.

including battery

*The specifications are subject to change without notice.
