Untitled DocumentInput Impedance: Mic: 4,000 ohms
Line: 30,000 ohms Output Impedance: Line: 200 ohms Mic: 320 ohms Maximum Input Level: Mic: -20 dBV
Line: +30 dBV Maximum Output Level: Line: +14 dBm (600 ohms)
Mic: -40 dBm (600 ohms) Nominal Output Level: (0VU) Line: +4 dBm (600 ohms), +4.4 dBV (open circuit)
Mic: -46 dBm (600 ohms), -44 dBV (open circuit) Maximum Gain: >=70 dB Frequency Response: 60 Hz to 30 kHz at -3 dB points Equivalent Input Noise: -120 dBV (150 ohms) at maximum gain Input Attenuation: 10 dB Mic Line Input Pads: 50 dB Microphone Phantom Power: +12V DC Control Voltage Out: +4V DC Power Supply: 12V AC or 15-18V DC, either polarity; 150 mA, minimum Operating Temperature: 32 to 104 F (0 to 40 C) Dimensions:210 mm W x 327 mm D x 44 mm H (including feet, knobs and connectors) Accessories Included: System link cable, manual, rack adaptors, AC power supply
