Specifikacije Studiomaster C2S-2

Channels

6

Mic Inputs

2

Stereo Inputs

4

Frequency Response

20Hz-20kHz (+/-1dB)

Distortion

<0.08% @ -10dBu

Residual Noise

<-98dB

Gain Range Mic Input

0dB to +45dB

Line Input

-20dB to +25dB

Input Impedance    Line

20k ohm balanced

Playback+ CDMP3

24k ohm unbalanced

EQ Hi

+/-15dB @ 12kHz

Lo

+/-15dB @ 80Hz

Maximum Output    Main Mix

+21dB +/-2dB

Aux Send

+18dBu +/-2B

Output Impedance  Record

1k ohm

Headphones

25k ohm

USB

2 channel playback/record

Dimensions (WxHxD)

244mm x 165mm x75mm

Power Supply

Wall adaptor 100-240V ~ 50/60Hz

Power Consumption

11W
