Specifikacije Studiomaster PAX12+

Speaker:

12″ custom design high output

HF Unit:

High frequency tweeter

Finish:

Black carpet covering, corner protectors, feet, scoop handle

Power Output:

120W @ 8ohms RMS

@ 1% THD:

150W @ 4ohm (with PX12) RMS

Distortion (amp):

0.008% (50W @ 8ohms)

Maximum SPL:

116dB

Mic Input Impedance:

6k ohms balanced

Line Input Impedance:

33k ohm balanced

Mic Input Sensitivity:

-30dBu

Line Input Sensitivity:

-10dBu

Equalisation:

Hi 12dB@5kHz Q=2, Mid 15dB@1.5kHz Q=0.9, Lo 12dB@90Hz Q=3.6

Notch Filter:

-12dB @ 300Hz to 6kHz, Q=3.3, switchable with LED

Input Connection:

Balanced XLR and Jack

Output Connection:

Jack link out socket

Power Requirements:

230V Range 10% ~ 50/60Hz 4A Max

Voltage Selector:

115V Range 10% ~ 50/60Hz 8A Max

Dimension W*H*D:

553 x 380 x 450 (mm)

Weight (net/shipping):

16kg / 19kg
