Specifications

Controllers

PORTAMENTO 1 slider
PORTAMENTO 1 switch
PORTAMENTO 2 slider
PORTAMENTO 2 switch

CLOCK RATE slider
LAG TIME slider
SAMPLE & HOLD knob

FREQUENCY slider
DELAY slider
FREQUENCY RANGE switch

Indicators

PORTAMENTO 1 indicator
PORTAMENTO 2 indicator

CLOCK RATE indicator

Connectors

CV IN 1 jack: Miniature phone type
CV OUT 1 jack: Miniature phone type
PORTAMENTO CV IN1 jack: Miniature phone type
CV IN 2 jack: Miniature phone type
CV OUT 2 jack: Miniature phone type
PORTAMENTO CV IN2 jack: Miniature phone type

EXTERNAL CLOCK IN jack: Miniature phone type
CLOCK OUT jack: Miniature phone type
SAMPLE & HOLD OUT jack: Miniature phone type
EXTERNAL SIGNAL IN jack: Miniature phone type

DELAY TRIGGER jack: Miniature phone type
CV IN jack: Miniature phone type
SQUARE jack: Miniature phone type
TRIANGLE jack: Miniature phone type
SAW jack: Miniature phone type
INVERTED SAW jack: Miniature phone type
SINE WAVE jack: Miniature phone type

PINK NOISE jack: Miniature phone type
WHITE NOISE jack: Miniature phone type

RING MODULATOR X IN jack: Miniature phone type
RING MODULATOR Y IN jack: Miniature phone type
RING MODULATOR OUT jack: Miniature phone type

Power Supply

Eurorack power

Current draw

110 mA (+12 V)
85 mA (-12 V)

Accessories

Owner's Manual
Leaflet "USING THE UNIT SAFELY"
Eurorack installation screws (4 pcs)
Eurorack power cable

Size and Weight

Width

80.8 mm
3-3/16 inches
16 HP

Depth

57.2 mm
2-1/4 inches

Height

128.5 mm
5-1/16 inches

Weight

201 g
8 oz
