Nominal Input Level

-20 dBu

Nominal output Level

-20 dBu

Control

Pedal

Indicators

A (red), B (yellow)

Connectors

A jack, B jack, IN/OUT jack

Current Draw

5 mA or less
* Expected battery life under continuous use: Carbon: 100 hours
* This figure will vary depending on the actual conditions of use.

Power Supply

Dry Battery [R03/LR03 (AAA) type] x 2

Accessories

Owner's Manual, Dry Battery [R03/LR03 (AAA) type] x 2, Number Sticker

Size and Weight

Width

96 mm
3-13/16 inches

Depth

90 mm
3-9/16 inches

Height

43 mm
1-3/4 inches

Weight

240 g
0 lbs. 9 oz.

* 0 dBu=0.775 Vrms

*The specifications are subject to change without notice.
