Input Impedance

1 M ohms

Output Impedance

10 k ohms or greater

Residual Noise Level

-95 dBu (IHF-A, Typ.)

Connectors

INPUT Jack, OUTPUT Jack A (mono)/ B, AC Adaptor Jack (DC 9 V)

Power Supply

DC 9 V: Dry Battery 9 V type (6F22/9 V), AC Adaptor

Current Draw

22 mA (DC 9 V)

Accessories

Dry Battery 9 V type (6F22/9 V)

Option

AC Adaptor (PSA-Series)

Size and Weight ( incl. battery )

Width

73 mm
2-7/8 inches

Depth

129 mm
5-1/8 inches

Height

59 mm
2-3/8 inches

Weight

400 g
0 lbs. 15 oz.

* 0 dBu = 0.775 Vrms

*The specifications are subject to change without notice.
