- Input Impedance
- 470 k ohms
- Output Impedance
- 10 k ohms or greater
- Connectors
- INPUT Jack, OUTPUT Jack, AC Adaptor Jack (DC 9 V)
- Power Supply
- DC 9 V: Dry Battery 9 V type (6F22/9 V), AC Adaptor
- Current Draw
- 6 mA (DC 9 V)
- Accessories
- Dry Battery 9 V type (6F22/9 V)
- Option
- AC Adaptor (PSA-Series)
- Size and Weight ( incl. battery )
- Width
- 73 mm
2-7/8 inches - Depth
- 129 mm
5-1/8 inches - Height
- 59 mm
2-3/8 inches - Weight
- 400 g
0 lbs. 15 oz. - * 0 dBu = 0.775 Vrms
- *The specifications are subject to change without notice.
